HD 1080P AHD CCTV Camera Security System 2.0MP Outdoor Night Vision Surveillance
Overview
Quick Details
- Channels:
-
4
- Warranty:
-
2 years
- Network:
-
ONVIF
- Function:
-
Wide Angle
- Application:
-
Outdoor
- Customized support:
-
Customized logo
- Place of Origin:
-
Guangdong, China
- Brand Name:
-
sunivision
- Model Number:
-
AP-F175A27C
- Sensor:
-
CMOS
- Special Features:
-
Built-in Siren, Waterproof / Weatherproof
- Certification:
-
ce
- Data Storage Options:
-
Cloud
- Video Compression Format:
-
H.264
- Technology:
-
Infrared
- Image sensor:
-
XM330V200+SC2235E
- Image resoluion:
-
2megapixel
- Infrared distance:
-
20M
- IR LED:
-
24pcs
- Operation Temp:
-
-10C~+50C
- Pixels:
-
2M Pixels
- Color:
-
white
- Housing:
-
Weatherproof, IP 66
HD 1080P AHD CCTV Camera Security System 2.0MP Outdoor Night Vision Surveillance
| Model NO. | AP-F175A27C |
| AHD Camera | |
| Image Sensor | SC2235E |
| DSP | XM330V200 |
| Image Resolution | PAL: 25fps@720P(1280×1920); NTSC: 30fps@720P(1280×19200) |
| Effective Pixels | 1280(H)×1920(V) , 2MP |
| TV System | PAL/NTSC |
| Electronic Shutter | 1/25s~1/50,000s , 1/30s~1/60,000s |
| Sync System | Internal |
| Usable Illumination | 0.01Lux |
| S/N Ratio | ≥50dB |
| Scanning System | Progressive Scan |
| Video Output Mode | AHD/CVBS (960H) (BNC) |
| Transmission Distance | Over 500m via 75-3 coaxial cable |
| Lens | |
| Focus Length | Board Lens 2.8-12mm |
| Focus Control | varifocal lens |
| Lens Type | varifocal lens |
| Pixels | 2M Pixels |
| Auto Iris Support | NO |
| Night Vision | |
| Infrared LED | F 5X24PCS |
| Infrared Distance | 20M |
| IR Status | Under 10 Lux by CDS |
| IR Power On | CDS Auto Control |
| Camera Features | |
| Day/Night | Auto (ICR) / Color / B&W |
| OSD Menu Language | EN, CN, DE, FRA, IT, ES, |
| PL, RU, PT, NL, TR | |
| White Balance | Auto/Manual |
| Gain Control | Auto |
| Noise Reduction | 3D NR |
| Picture Adjustment | Yes |
| OSD Support | Yes |
| General | |
| Weatherproof Housing | YES, IP66 |
| Anti-cut Bracket | YES, |
| Dual Voltage | NO |
| IR Cut Filter | YES |
| Heater | NO |
| Operation Temperature | -10℃ ~ +50℃ RH95% Max |
| Storage Temperature | -20℃ ~ +60℃ RH95% Max |
| Power Source | DC12V±10%, 350mA |
