China Manufacutrer's price 8CH 4*5M/8*4M H265 support 1*SATA HDD ONVIF APP: XMEYE cctv camera with voice recorder Manufacture and Factory

Manufacutrer's price 8CH 45M/84M H265 support 1*SATA HDD ONVIF APP: XMEYE cctv camera with voice recorder

Send email to us

Overview

Quick Details

Product name:

8 Channel Mobile DVR(HDD Storage)

Resolution:

H.265 4MP,5MP, 4K

Video Output:

1*VGA,1*,1*BNC

HDD:

1SATA Max 8TB

Certificate:

CE RoHS

Warranty:

2 Years

Type:

8CH Vehicle Mobile DVR

IP Camera Input:

4*4K/4*5M/8*1080P

Playback:

1*4K /2*5M /2*4M/ 4*1080P

Video Compression Format:

H.265

Product Description

Connection Instruction:

	Model	AP-DNVR8008T-Q
System	Main processor	Hi3798M
System	Operating system	Embedded Linux
Interface	Operator interface	16-bit true color graphic menu operation interface,support mouse operation
Interface	Preview	1/4/8/16
Audio&video	Video input	44K/45M/84M/16960P
	Decode	H.264/H.265
	Monitor quality	Max 4K
	Playback quality	4K/5M/4M/960P
	Standard	Video: PAL, NTSC; Audio:G.711A
	Motion detection	Depend on camera
	Intercom	Usupport
Record & Backup	Record mode	Manual>Alarm>Dynamic Detection>TimingDetection>Timing
	Local playback	14K/25M/24M/4960P
	Search mode	Ssearch by time/calendar/event/channel
	Record storage	HDD, network
	Backup mode	Network backup, USB hard disk, USB burner, SATA burner
External interface	Video out	1ch
	Audio I/O	0/0
	Alarm I/O	0/0
	Network interface	1*RJ45 10M/100M ,Adaptive Ethernet port
	PTZ control	Control PTZ device by network
	USB	2*USB2.0 ports
	HDD	1 *SATA(Max 8T for each)
General		Support
	GB28181	Optional
	Work environment	Temperature:0℃-+55℃ , Humidity:10%-90%RH , Atm:86kpa-106kp
	Weight	Around 1KG
	Power supply	12V/2A
	Dimension	255(L)* 236mm(W)* 44mm(H)
